Standard Features:

• Controls one linear actuator (actuator must have a potentiometer for position feedback)

• 6 user-definable position setpoints (non-volatile retention)

• Actuator will move to any one of the 6 user-defined setpoints

• Actuator can be manually extended or retracted

• Output switching is with a MOSFET H-Bridge and has dynamic braking

• LED indication of operational status

• Ruggedized, waterproof package design

• Integrated waterproof control input/output connector

• Epoxy potted controller with four 1/4” mounting holes

• Potentiometer excitation: 5 VDC

• Input triggering: Sinking, with internal pull-ups

• Output signaling: Sinking, 500mA maximum per point

• Input/output voltage: 12 VDC (nominal)

• Duty cycle: 25% or 2 minutes maximum continuous operation in 8 minutes

• Fuse: 30 Amp
