PBK100-C |
BK-100 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5.6 |
|
PBK100-D |
BK-100 Sheave - 7/8" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5.6 |
|
PBK100-F |
BK-100 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5.6 |
|
PBK100-G |
BK-100 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5.6 |
|
PBK100-H |
BK-100 Sheave - 1 3/16" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5.6 |
|
PBK110-H |
BK-110 Sheave - 1 3/16" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
6.4 |
|
PBK120-H |
BK-120 Sheave - 1 3/16" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
7.4 |
|
PBK100-I |
BK-100 Sheave - 1 1/4" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5.6 |
|
PBK100-J |
BK-100 Sheave - 1 3/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5.6 |
|
PBK100-K |
BK-100 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
5.6 |
|
PBK100H-QD |
BK-100H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
5.2 |
|
PBK105-F |
BK-105 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5.8 |
|
PBK105-J |
BK-105 Sheave - 1 3/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5.8 |
|
PBK105-K |
BK-105 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
5.8 |
|
PBK105H-QD |
BK-105H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
5.5 |
|
PBK110-C |
BK-110 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
6.4 |
|
PBK110-F |
BK-110 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
6.4 |
|
PBK110-G |
BK-110 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
6.4 |
|
PBK110-J |
BK-110 Sheave - 1 3/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
6.4 |
|
PBK110-K |
BK-110 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
6.4 |
|
PBK110H-QD |
BK-110H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
6 |
|
PBK115-F |
BK-115 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
6.9 |
|
PBK115-J |
BK-115 Sheave - 1 3/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
6.9 |
|
PBK115-K |
BK-115 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
6.9 |
|
PBK115H-QD |
BK-115H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
6.4 |
|
PBK120-C |
BK-120 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
7.4 |
|
PBK120-F |
BK-120 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
7.4 |
|
PBK120-J |
BK-120 Sheave - 1 3/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
7.4 |
|
PBK120-K |
BK-120 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
7.4 |
|
PBK120H-QD |
BK-120H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
6.9 |
|
PBK130-C |
BK-130 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
8.4 |
|
PBK130-F |
BK-130 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
8.4 |
|
PBK130-G |
BK-130 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
8.4 |
|
PBK130-K |
BK-130 Sheave - 1 7/16" Bore, 3/8" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
8.4 |
|
PBK130H-QD |
BK-130H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
6.9 |
|
PBK140-C |
BK-140 Sheave - 3/4" Bore, 1/4" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
9.4 |
|
PBK140-F |
BK-140 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
9.4 |
|
PBK140-K |
BK-140 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
9.4 |
|
PBK140H-QD |
BK-140H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
8.5 |
|
PBK150H-QD |
BK-150H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
9.5 |
|
PBK160-F |
BK-160 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
11.4 |
|
PBK160-G |
BK-160 Sheave - 1 1/8" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
11.4 |
|
PBK160-I |
BK-160 Sheave - 1 1/4" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
11.4 |
|
PBK160-K |
BK-160 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
11.4 |
|
PBK160H-QD |
BK-160H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
9.8 |
|
PBK190-F |
BK-190 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
13.4 |
|
PBK190-I |
BK-190 Sheave - 1 1/4" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
13.4 |
|
PBK190-K |
BK-190 Sheave - 1 7/16" Bore, 3/8" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
13.4 |
|
PBK190H-QD |
BK-190H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
12.8 |
|
PBK20-B |
BK-20 Sheave - 5/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
1 |
|
PBK24-A |
BK-24 Sheave - 1/2" Bore, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.4 |
|
PBK24-B |
BK-24 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.4 |
|
PBK24-C |
BK-24 Sheave 3/4" Bore, 3/16" keyway, 5/16"Setscrew, light duty, A-B combination, painted finish |
0.4 |
|
PBK24-D |
BK-24 Sheave 7/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
0.4 |
|
PBK25-A |
BK-25 Sheave - 1/2" Bore, 1/8" keyway, 10-24 Setscrew, light duty, A-B combination, painted finish |
0.5 |
|
PBK25-B |
BK-25 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.5 |
|
PBK25-C |
BK-25 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.5 |
|
PBK25-D |
BK-25 Sheave - 7/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.5 |
|
PBK26-A |
BK-26 Sheave 1/2" Bore, 1/8" keyway, 10-24" Setscrew, light duty, A-B combination, painted finish |
0.6 |
|
PBK26-B |
BK-26 Sheave - 5/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
0.6 |
|
PBK26-C |
BK-26 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
0.6 |
|
PBK26-D |
BK-26 Sheave 7/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
0.6 |
|
PBK27-A |
BK-27 Sheave - 1/2" Bore, light duty, A-B combination, painted finish |
0.6 |
|
PBK27-B |
BK-27 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.6 |
|
PBK27-C |
BK-27 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
0.6 |
|
PBK27-D |
BK-27 Sheave - 7/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
0.6 |
|
PBK27-G |
BK-27 Sheave - 1 1/8" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.6 |
|
PBK28-22MM |
2.95OD Steel Sheave,A-B Combination,22mm Bore,7mm KW,2SS, painted finish |
1 |
|
PBK28-A |
BK-28 Sheave - 1/2" Bore, 1/8" keyway, 10-24" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK28-B |
BK-28 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK28-C |
BK-28 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK28-D |
BK-28 Sheave - 7/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK28-F |
BK-28 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK28-G |
BK-28 Sheave - 1 1/8" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK30-A |
BK-30 Sheave - 1/2" Bore,no keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK30-B |
BK-30 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK30-C |
BK-30 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK30-D |
BK-30 Sheave - 7/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK30-F |
BK-30 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK30-G |
BK-30 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK30H-QD |
BK-30H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
1.2 |
|
PBK32-A |
BK-32 Sheave - 1/2" Bore, 1/8" keyway, 10-24 Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK32-B |
BK-32 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK32-C |
BK-32 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK32-D |
BK-32 Sheave - 7/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK32-F |
BK-32 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
0.8 |
|
PBK32H-QD |
BK-32H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
1.4 |
|
PBK34-A |
BK-34 Sheave - 1/2" Bore, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.3 |
|
PBK34-B |
BK-34 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.3 |
|
PBK34-C |
BK-34 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.3 |
|
PBK34-D |
BK-34 Sheave - 7/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
1.3 |
|
PBK34-F |
BK-34 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.3 |
|
PBK34-G |
BK-34 Sheave - 1 1/8" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.3 |
|
PBK34H-QD |
BK-34H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
1.6 |
|
PBK36-A |
BK-36 Sheave 1/2" Bore, 1/8" keyway, 10-24 Setscrew, light duty, A-B combination, painted finish |
1.5 |
|
PBK36-B |
BK-36 Sheave 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.5 |
|
PBK36-C |
BK-36 Sheave 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
1.5 |
|
PBK36-D |
BK-36 Sheave - 7/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.5 |
|
PBK36-F |
BK-36 Sheave 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.5 |
|
PBK36-G |
BK-36 Sheave - 1 1/8" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.5 |
|
PBK36H-QD |
BK-36H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
1.2 |
|
PBK40-A |
BK-40 Sheave - 1/2" Bore, no keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.5 |
|
PBK40-B |
BK-40 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.5 |
|
PBK40-C |
BK-40 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.5 |
|
PBK40-D |
BK-40 Sheave - 7/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.5 |
|
PBK40-F |
BK-40 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.5 |
|
PBK40-G |
BK-40 Sheave - 1 1/8" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.5 |
|
PBK40H-QD |
BK-40H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
1.4 |
|
PBK45-A |
BK-45 Sheave - 1/2" Bore, 1/8" keyway, 10-24 Setscrew, light duty, A-B combination, painted finish |
1.8 |
|
PBK45-B |
BK-45 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.8 |
|
PBK45-C |
BK-45 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.8 |
|
PBK45-D |
BK-45 Sheave - 7/8" Bore, 1/4" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
1.8 |
|
PBK45-F |
BK-45 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.8 |
|
PBK45-G |
BK-45 Sheave - 1 1/8" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.8 |
|
PBK45H-QD |
BK-45H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
1.8 |
|
PBK47-A |
BK-47 Sheave - 1/2" Bore, 1/8" keyway, 10-24 Setscrew, light duty, A-B combination, painted finish |
1.9 |
|
PBK47-B |
BK-47 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.9 |
|
PBK47-C |
BK-47 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.9 |
|
PBK47-D |
BK-47 Sheave - 7/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
1.9 |
|
PBK47-F |
BK-47 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.9 |
|
PBK47-G |
BK-47 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
1.9 |
|
PBK47H-QD |
BK-47H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
2.2 |
|
PBK50-A |
BK-50 Sheave - 1/2" Bore, no keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2 |
|
PBK50-B |
BK-50 Sheave - 5/8" Bore, 3/16" keyway,5/16" Setscrew, light duty, A-B combination, painted finish |
2 |
|
PBK50-C |
BK-50 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
2 |
|
PBK50-D |
BK-50 Sheave - 7/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2 |
|
PBK50-F |
BK-50 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2 |
|
PBK50-F2SS |
BK-50 Sheave, 1" Bore, 1/4" keyway, 2 Setscrews, painted finish |
2 |
|
PBK50-G |
BK-50 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2 |
|
PBK50H-QD |
BK-50H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
2 |
|
PBK52-A |
BK-52 Sheave - 1/2" Bore, no keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2 |
|
PBK52-B |
BK-52 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2 |
|
PBK52-C |
BK-52 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2 |
|
PBK52-D |
BK-52 Sheave - 7/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2 |
|
PBK52-F |
BK-52 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2 |
|
PBK52-F2SS |
BK52 Sheave, 1" Bore, 1/4" Keyway, 2 Setscrews, painted finish |
2 |
|
PBK52-G |
BK-52 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2 |
|
PBK52H-QD |
BK-52H Sheave with Bore to fit "H" bushing, light duty, A-B Combination groove, painted finish |
2.1 |
|
PBK55-A |
BK-55 Sheave - 1/2" Bore, NO keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.2 |
|
PBK55-B |
BK-55 Sheave - 5/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
2.2 |
|
PBK55-C |
BK-55 Sheave - 3/4" Bore, 1/4" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
2.2 |
|
PBK55-D |
BK-55 Sheave - 7/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
2.2 |
|
PBK55-F |
BK-55 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.2 |
|
PBK55-F2SS |
BK55 Sheave, 1" Bore, 1/4" Keyway, 2 Setscrews, painted finish |
2.2 |
|
PBK55-G |
BK-55 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.2 |
|
PBK55H-QD |
BK-55H Sheave with Bore to fit "H" bushing, light duty, A-B Combination groove, painted finish |
2.7 |
|
PBK57-B |
BK-57 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.3 |
|
PBK57-C |
BK-57 Sheave - 3/4" Bore, 1/4" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
2.3 |
|
PBK57-D |
BK-57 Sheave - 7/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
2.3 |
|
PBK57-F |
BK-57 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.3 |
|
PBK57-G |
BK-57 Sheave - 1 1/8" Bore,5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.3 |
|
PBK57H-QD |
BK-57H Sheave, with Bore to fit "H" bushing, light duty, A-B Combination groove, painted finish |
2.7 |
|
PBK60-A |
BK-60 Sheave - 1/2" Bore, 1/8" keyway, 10-24 Setscrew, light duty, A-B combination, painted finish |
2.3 |
|
PBK60-B |
BK-60 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.3 |
|
PBK60-C |
BK-60 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
2.3 |
|
PBK60-D |
BK-60 Sheave - 7/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.3 |
|
PBK60-F |
BK-60 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.3 |
|
PBK60-F2SS |
BK-60 Sheave, 1" Bore, 1/4" Keyway, 2 Setscrews, painted finish |
2.4 |
|
PBK60-G |
BK-60 Sheave - 1 1/8" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.3 |
|
PBK60H-QD |
BK-60H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
2.5 |
|
PBK62-A |
BK-62 Sheave - 1/2" Bore, 1/8" keyway, 10-24 Setscrew, light duty, A-B combination, painted finish |
2.4 |
|
PBK62-B |
BK-62 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.4 |
|
PBK62-C |
BK-62 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
2.4 |
|
PBK62-D |
BK-62 Sheave - 7/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
2.4 |
|
PBK62-F |
BK-62 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.4 |
|
PBK62-G |
BK-62 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.4 |
|
PBK62H-QD |
BK-62H Sheave, with Bore to fit "H" bushing, light duty, A-B Combination groove, painted finish |
2.6 |
|
PBK65-B |
BK-65 Sheave - 5/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
2.7 |
|
PBK65-C |
BK-65 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
2.7 |
|
PBK65-F |
BK-65 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.7 |
|
PBK65-F2SS |
BK-65 Sheave, 1" Bore, 1/4" Keyway, 2 Setscrews, painted finish |
2.6 |
|
PBK65-G |
BK-65 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.7 |
|
PBK65H-QD |
BK-65H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
2.8 |
|
PBK67-B |
BK-67 Sheaves - 5/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
2.8 |
|
PBK67-C |
BK-67 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.8 |
|
PBK67-F |
BK-67 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.8 |
|
PBK67-G |
BK-67 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
2.8 |
|
PBK67H-QD |
BK-67H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
2.9 |
|
PBK70-B |
BK-70 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
3.3 |
|
PBK70-C |
BK-70 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
3.3 |
|
PBK70-F |
BK-70 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
3.3 |
|
PBK70-F2SS |
BK-70 Sheave, 1" Bore, 1/4" Keyway, 2 Setscrews, painted finish |
3 |
|
PBK70-G |
BK-70 Sheave - 1 1/8" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
3.3 |
|
PBK70-K |
BK-70 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
3.3 |
|
PBK70H-QD |
BK-70H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
2.8 |
|
PBK72-C |
BK-72 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
3.9 |
|
PBK72-F |
BK-72 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
3.9 |
|
PBK72-G |
BK-72 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
3.9 |
|
PBK72-J |
BK-72 Sheave - 1 3/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
3.9 |
|
PBK72-K |
BK-72 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
3.9 |
|
PBK72H-QD |
BK-72H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
3.1 |
|
PBK75-C |
BK-75 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
3.9 |
|
PBK75-F |
BK-75 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
3.9 |
|
PBK75-F2SS |
BK75 Sheave, 1" Bore, 1/4" Keyway, 2 Setscrews, painted finish |
3.8 |
|
PBK75-G |
BK-75 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
3.9 |
|
PBK75-K |
BK-75 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
3.9 |
|
PBK75H-QD |
BK-75H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
3.3 |
|
PBK77-C |
BK-77 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
4.1 |
|
PBK77-F |
BK-77 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
4.1 |
|
PBK77-G |
BK-77 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
4.1 |
|
PBK77-J |
BK-77 Sheave - 1 3/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
4.1 |
|
PBK77-K |
BK-77 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
4.1 |
|
PBK77H-QD |
BK-77H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
3.8 |
|
PBK80-B |
BK-80 Sheave - 5/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
4.4 |
|
PBK80-C |
BK-80 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
4.4 |
|
PBK80-D |
BK-80 Sheave - 7/8" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
4.4 |
|
PBK80-F |
BK-80 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
4.4 |
|
PBK80-F2SS |
BK-80 Sheave, 1" Bore, 1/4" Keyway, 2 Setscrews, painted finish |
4.2 |
|
PBK80-G |
BK-80 Sheave - 1 1/8" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
4.4 |
|
PBK80-I |
BK-80 Sheave - 1 1/4" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
4.4 |
|
PBK80-J |
BK-80 Sheave - 1 3/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
4.4 |
|
PBK80-K |
BK-80 Sheave - 1 7/16: Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
4.4 |
|
PBK80H-QD |
BK-80H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
3.4 |
|
PBK85-C |
BK-85 Sheave - 3/4" Bore, 1/4" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
5 |
|
PBK85-F |
BK-85 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5 |
|
PBK85-F2SS |
BK-85 Sheave, 1" Bore, 1/4" Keyway, 2 Setscrews, painted finish |
4.8 |
|
PBK85-G |
BK-85 Sheave - 1 1/8" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5 |
|
PBK85-J |
BK-85 Sheave - 1 3/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5 |
|
PBK85-K |
BK-85 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
5 |
|
PBK85H-QD |
BK-85H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
3.8 |
|
PBK90-C |
BK-90 Sheave - 3/4" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5 |
|
PBK90-D |
BK-90 Sheave - 7/8" Bore, 3/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5 |
|
PBK90-F |
BK-90 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5 |
|
PBK90-G |
BK-90 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5 |
|
PBK90-J |
BK-90 Sheave - 1 3/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5 |
|
PBK90-K |
BK-90 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
5 |
|
PBK90H-QD |
BK-90H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
4.3 |
|
PBK95-C |
BK-95 Sheave - 3/4" Bore, 3/16" keyway, 1/4" Setscrew, light duty, A-B combination, painted finish |
5.4 |
|
PBK95-F |
BK-95 Sheave - 1" Bore, 1/4" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5.4 |
|
PBK95-G |
BK-95 Sheave - 1 1/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5.4 |
|
PBK95-J |
BK-95 Sheave - 1 3/8" Bore, 5/16" keyway, 5/16" Setscrew, light duty, A-B combination, painted finish |
5.4 |
|
PBK95-K |
BK-95 Sheave - 1 7/16" Bore, 3/8" keyway, 3/8" Setscrew, light duty, A-B combination, painted finish |
5.4 |
|
PBK95H-QD |
BK-95H Sheave with Bore to fit "H" Bushing, light duty, A-B Combination groove, painted finish |
5 |
|
PAK17-A |
AK-17 Sheave, 1.75" OD, 1/2" Bore with Setscrew, NO Keyway |
1 |
|
PAK17-B |
AK-17 Sheave, 1.75" OD, 5/8" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK20-A |
AK-20 Sheave, 2.00" OD, 1/2" Bore with Setscrew, NO Keyway |
0.4 |
|
PAK20-B |
AK-20 Sheave, 2.00" OD, 5/8" Bore with Setscrew, 3/16" Keyway |
0 |
|
PAK20-C |
AK-20 Sheave, 2.00" OD, 3/4" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK22-A |
AK-22 Sheave, 2.20" OD, 1/2" Bore with Setscrew, NO Keyway |
1 |
|
PAK22-B |
AK-22 Sheave, 2.20" OD, 5/8" Bore with Setscrew, 3/16" Keyway |
0.5 |
|
PAK22-C |
AK-22 Sheave, 2.20" OD, 3/4" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK25-A |
AK-25 Sheave, 2.50" OD, 1/2" Bore with Setscrew, NO Keyway |
0.4 |
|
PAK25-B |
AK-25 Sheave, 2.50" OD, 5/8" Bore with Setscrew, 3/16" Keyway |
0.4 |
|
PAK25-C |
AK-25 Sheave, 2.50" OD, 3/4" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK25-D |
AK-25 Sheave, 2.50" OD, 7/8" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK28-A |
AK-28 Sheave, 2.80" OD, 1/2" Bore with Setscrew, NO Keyway |
1 |
|
PAK28-B |
AK-28 Sheave, 2.80" OD, 5/8" Bore with Setscrew, 3/16" Keyway |
0.7 |
|
PAK28-C |
AK-28 Sheave, 2.80" OD, 3/4" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK30-A |
AK-30 Sheave, 3.05" OD, 1/2" Bore with Setscrew, NO Keyway |
0.6 |
|
PAK30-B |
AK-30 Sheave, 3.05" OD, 5/8" Bore with Setscrew, 3/16" Keyway |
0.96 |
|
PAK30-C |
AK-30 Sheave, 3.05" OD, 3/4" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK30-D |
AK-30 Sheave, 3.05" OD, 7/8" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK34-A |
AK-34 Sheave, 3.45" OD, 1/2" Bore with Setscrew, NO Keyway |
1 |
|
PAK34-B |
AK-34 Sheave, 3.45" OD, 5/8" Bore with Setscrew, 3/16" Keyway |
0.8 |
|
PAK34-C |
AK-34 Sheave, 3.45" OD, 3/4" Bore with Setscrew, 3/16" Keyway |
0.8 |
|
PAK34-D |
AK-34 Sheave, 3.45" OD, 7/8" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK39-B |
AK-39 Sheave, 3.75" OD, 5/8" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK41-A |
AK-41 Sheave, 3.95" OD, 1/2" Bore with Setscrew, NO Keyway |
1 |
|
PAK41-B |
AK-41 Sheave, 3.95" OD, 5/8" Bore with Setscrew, 3/16" Keyway |
1.2 |
|
PAK41-C |
AK-41 Sheave, 3.95" OD, 3/4" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK41-D |
AK-41 Sheave, 3.95" OD, 7/8" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK41-F |
AK-41 Sheave, 3.95" OD, 1/2" Bore with Setscrew, 3/16" Keyway |
1 |
|
PAK51-A |
AK-51 Sheave, 1/2" Bore, Keyway, 2 Setscrews, grey |
2 |
|
PAK51-F |
AK-51 Sheave, 1.00" Bore, Keyway, 2 Setscrews, grey |
1.8 |
|
PAK56-C |
AK-56 Sheave, 3/4" Bore, Keyway, 2 Setscrews, grey |
2.28 |
|
PAK61-9/16 |
AK-74 Sheave, 9/16" Bore, Keyway, 2 Setscrews, grey |
2.6 |
|
PAK74-F |
AK-74 Sheave, 1.00" Bore, Keyway, 2 Setscrews, grey |
4.16 |
|
PAS30-B |
1 groove sheave, no hub, 5/8" Bore, 3.05" OD, Keyway, (2) set screws, grey |
0.8 |
